High Speed Fermented Liquid Centrifugal Spray Dryer
Model: LT-1000;Material: SUS304, SUS316L, Ti;Max. Water Evaporation Capacity: 1000kg/h;Heating Method: Electricity + steam, fuel oil, gas, up to the user.;Applications: Medicine processing, chemicals processing, plastics processing, food processing, etc.


Contact: Mr Tang
E-mail: [email protected]
Mobile Phone: +86-13906177584
Website: www.tydrying.com
Address: Qiangzhou Town,Wuxi City,Jiangsu,China

Whats app:
+8613771018713

Brand Name: TIANYANG

Type: Fermented Liquid Spray Dryer

Model: LT-1000

Material: SUS304, SUS316L, Ti

Max. Water Evaporation Capacity: 1000kg/h

Heating Method: Electricity + steam, fuel oil, gas, up to the user.

Applications: Medicine processing, chemicals processing, plastics processing, food processing, etc.

Warranty: One year

Product Description

LT Series economic high performance high speed fermented liquid centrifugal spray drying equipment is a new spray drying machine researched and developed successfully by our company according to china's actual conditions after absorbing and digesting internationally advanced technology. It has features such as reasonable structure, stable performance, convenient operation, no dead corners, and no exposed bolts.

LT-1000 high speed fermented liquid centrifugal spray dryer adopts PLC automatic control. All operations are completed automatically according to the process parameters set by users. It fully meets the requirements for fermented liquid production in GMP.




Technical Specifications of Fermented Liquid Spray Dryer

Model

LT-1000

Max. Water Evaporation Capacity (kg/h)

1000kg/h

Material

SUS304, SUS316L

Inlet Temperature (℃)

140-350

Out Temperature (℃)

80-90

Spray Type

High Speed Centrifugal Atomizer

Applications

Medicine processing, chemicals processing, plastics processing, food processing, etc.

Transmission Form of Centrifugal Spray Head

Mechanical transmission

Atomization Rotated Speed (RPM)

12700

Spray Disc Diameter (mm)

180

Heating Method

Electricity + steam, fuel oil, gas, up to the user.

Electric Heating Maximum Power (KW)

Customized

Dimensions (L×W×H) mm

Customized

Dry Powder Recovery

95%


Main Features

1. Different types of solution, suspension, emulsion and cream paste material can be dry for a one-time production.

2. The fog moment and fog droplet of spray-drying can be slightly adjusted.

3. The hot air has been reasonable allocation, and the ceiling and walls sticky situation has been eliminated.

4. It is suitable for the drying of thermo-sensitive and non thermo-sensitive material at the same time. The product particles are smaller than pressure spray dryer.

5. Simplify the production process, easy to use, good liquidity and instant of the product.


Drying Material

* Inorganic: Aluminum nitride, zirconia, potassium fluoride, bentonite, kaolin, barium sulfate, lead sulfate, sodium aluminum, chromium oxide, titanium dioxide.

* Macromolecule Polymers: Urea-formaldehyde resin, PVC.

* Dyes: Dispersol red FB, reactive dyes, etc.

* Chemical Agents: Silica dioxide, diatomite, sodium silicate, wood calcium, sodium ligninsulfonate, naphthalene series water reducer.

* Pesticide: Carbendazol chloride wettable power.

* Food and Feed Additives: casein peptide phosphate, potassium sorbate, fish serum.

* Fertilizer: Potassium humate, sodium humate.
